$41.00–$1,038.00Price range: $41.00 through $1,038.00
This is a high-performance NFC tag in the right size. It is equipped with the NXP ICODE® SLIX2 chip and complies with ISO/IEC 15693, ISO/IEC 18000-3 and NFC Forum Type 5 standards. It provides fast data exchange and excellent read sensitivity for complex environments and medium-distance operations. Its optimized 65×30mm size combines compactness and antenna performance for flexible installation and reliable reading. With 2560 bits of built-in user memory, the tag can store a wide range of information types to meet diverse needs. Security features are further upgraded to include flexible access control and anti-counterfeiting technology, providing strong support for data security and brand protection. It can be applied to asset management, product authentication, smart packaging and interactive marketing, providing efficient and reliable intelligent solutions for enterprises.
Chip Manufacturer:NXP® Chip Type: ICODE® SLIX2 Data Retention: 50 years User Memory: 2560 bits UID Memory: 64 bits Write Endurance: 100,000 cycles Reading Rate: 53 kbit/s High data integrity: 16-bit CRC Lock mechanism: EAS, AFI, DSFID Anti-Collision Function: Yes Password: 32-bit protected EAS and AFI functionality Originality Signature: 32 bytes
Additional Information
Operating Environment: Label attach: 10°C ~ 40°C, 20% ~ 80% RH After label attached: -20°C ~ 50°C, 20% ~ 80% RH Storage Environment: 18°C ~ 28°C, 40% ~ 60% RH Handling Precautions: 1. Do not bend. 2. Keep away from water and collision. 3. Inlays with black-dot marks are bad ones, do not use.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag Roll OD: Max. 150 mm Core ID: 3 inch (76.20 ± 0.50 mm) Packing Quantity: 1000 Pcs/roll, per roll 0.646 kg
There are four ICs within NXP ICODE® SLIX family, that ICODE® SLIX, ICODE® SLIX2, ICODE® SLIX-L and ICODE® SLIX-S. The difference in between is mainly the size of EEPROM. ICODE® SLIX is the only type of IC DOES NOT support EAS selection and memory protection.
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
NXP ICODE® SLIX2 PET NFC Label 65×30mm
$41.00 – $1,038.00Price range: $41.00 through $1,038.00
This is a high-performance NFC tag in the right size. It is equipped with the NXP ICODE® SLIX2 chip and complies with ISO/IEC 15693, ISO/IEC 18000-3 and NFC Forum Type 5 standards. It provides fast data exchange and excellent read sensitivity for complex environments and medium-distance operations. Its optimized 65×30mm size combines compactness and antenna performance for flexible installation and reliable reading. With 2560 bits of built-in user memory, the tag can store a wide range of information types to meet diverse needs. Security features are further upgraded to include flexible access control and anti-counterfeiting technology, providing strong support for data security and brand protection. It can be applied to asset management, product authentication, smart packaging and interactive marketing, providing efficient and reliable intelligent solutions for enterprises.
Description
Features
Frequency Band
HF 13.56 MHz
Chip Type
NXP ICODE® SLIX2
International Standard
ISO/IEC 15693, ISO/IEC 18000-3, NFC Forum Tag Type 5
User Memory
2560 bits
UID Memory
64 bits
Read Range
Up to 1.5 m
Specifications
Physical Specifications
Material: PET
Label Size: 65×30 mm
Antenna Size: Diameter 27 mm
Technical Parameters
Operating Frequency: 13.56 MHz
Communication Protocol:
ISO/IEC 15693, ISO/IEC 18000-3, NFC Forum Tag Type 5
Read Range: Up to 1.5 m (depending on antenna geometry)
Capacitance: 23.5 pF
Operating mode: Passive
RF Specifications
Chip Manufacturer: NXP®
Chip Type: ICODE® SLIX2
Data Retention: 50 years
User Memory: 2560 bits
UID Memory: 64 bits
Write Endurance: 100,000 cycles
Reading Rate: 53 kbit/s
High data integrity: 16-bit CRC
Lock mechanism: EAS, AFI, DSFID
Anti-Collision Function: Yes
Password: 32-bit protected EAS and AFI functionality
Originality Signature: 32 bytes
Additional Information
Operating Environment:
Label attach: 10°C ~ 40°C, 20% ~ 80% RH
After label attached: -20°C ~ 50°C, 20% ~ 80% RH
Storage Environment:
18°C ~ 28°C, 40% ~ 60% RH
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Inlays with black-dot marks are bad ones, do not use.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Roll OD: Max. 150 mm
Core ID: 3 inch (76.20 ± 0.50 mm)
Packing Quantity: 1000 Pcs/roll, per roll 0.646 kg
cr80 | 86×54×0.88mm
RFID Card ICODE® SLIX
Blank or custom printed RFID card with ICODE® SLIX, operate at 13.56MHz and supporting ISO/IEC 15693 & NFC Forum Tag Type 5.
There are four ICs within NXP ICODE® SLIX family, that ICODE® SLIX, ICODE® SLIX2, ICODE® SLIX-L and ICODE® SLIX-S. The difference in between is mainly the size of EEPROM. ICODE® SLIX is the only type of IC DOES NOT support EAS selection and memory protection.
Unique Identifier (UID): 64 bits
User Memory: 896 bits
EEPROM: 1024 bits, organized in 32 blocks of 4 bytes each
Operating frequency: 13.56 MHz
Operating distance: Up to 1.5 meter
Data Transfer Rate: Up to 53 kbit/s
Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type
Input capacitance: 23.5 pF / 97 pF
Lock mechanism for DSFID, AFI, EAS
Password (32-bit) protected EAS and AFI functionality
anti-collision: Yes
Data retention: 50 years
Write endurance: 100,000 cycles
Unique Identifier (UID): 64 bits
User Memory: 2528 bits
EEPROM: 2560-bit user memory, 80 blocks of 4 bytes each
Operating frequency: 13.56 MHz
Operating distance: Up to 1.5 meter
Data Transfer Rate: Up to 53 kbit/s
Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type
Input capacitance: 23.5 pF
Lock mechanism for DSFID, AFI, EAS
Password (32-bit) protected EAS and AFI functionality
Password (32-bit) protected Label Destroy
Password (32-bit) protected Privacy Mode
anti-collision: Yes
Data retention: 50 years
Write endurance: 100,000 cycles
Unique Identifier (UID): 64 bits
User Memory: 256 bits
EEPROM: 512 bits, organized in 16 blocks of 4 bytes each
Operating frequency: 13.56 MHz
Operating distance: Up to 1.5 meter
Data Transfer Rate: Up to 53 kbit/s
Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type
Input capacitance: 23.5 pF / 97 pF
Lock mechanism for DSFID, AFI, EAS
Password (32-bit) protected EAS and AFI functionality
Password (32-bit) protected Label Destroy
Password (32-bit) protected Privacy Mode
anti-collision: Yes
Data retention: 50 years
Write endurance: 100,000 cycles
Unique Identifier (UID): 64 bits
User Memory: 1280 bits
EEPROM: 2048 bits (2 KB), organized in 64 blocks of 4 bytes each
Operating frequency: 13.56 MHz
Operating distance: Up to 1.5 meter
Data Transfer Rate: Up to 53 kbit/s
Communication Protocol: ISO15693, ISO18000-3, NFC Forum Tag 5 Type
Input capacitance: 23.5 pF / 97 pF
Lock mechanism for DSFID, AFI, EAS
Password (32-bit) protected EAS and AFI functionality
Password (32-bit) protected Label Destroy
Password (32-bit) protected Privacy Mode
anti-collision: Yes
Data retention: 50 years
Write endurance: 100,000 cycles
