UHF 12-dBi RFID Antenna ISO 18000-6C
$154.00
The UHF RFID antenna 12dBi features high sensitivity and outstanding reading performance, supporting long-distance, high-volume tag reading and writing with precision speed, and high security. It also has an IP67 high protection rating, excellent waterproof performance, and easy installation, making it suitable for a wide range of applications, including smart transportation, logistics, warehouse management, event management, production line management, smart retail, national defense security, power asset management, financial management, and medical equipment management.
Description
Features
Frequency Band
UHF 860~960 MHz
International Standard
ISO/IEC 18000-6C, EPC C1G2
IP Rating
IP67
Gain Values
12 dBi
Wind resistance
60 m/s
Installation method
Pole-mounting
Specifications
Physical Specifications
Dimensions: 445x445x30 mm
Weight: 2.66 kg
Shell material: ABS
Radiation plate material: Aluminum
Interface Form: N female
IP rating: IP67
Installation
Installation: Pole-mounting
Diameter of support rod: 30–50 mm
Technical Parameters
Frequency: 865~868 MHz | 902~928 MHz
Protocol: ISO/IEC 18000-6C, EPC C1G2
Horizontal Angle: 40°
Vertical Angle: 38°
Polarization: Circular Polarization (right-handed)
Standing Wave Ratio: ≤ 1.3
Gain Values: 12 dBi
Antenna front-to-back ratio: ≥ 17 dB
Characteristic impedance: 50Ω
Maximum input power: 20W
Environmental Spec
Operating Limits: -40°C ~ 60°C, DC grounding
Wind Resistance: 60 m/s
Reading Range H-side
Reading Range E-side
RFID Readers to Match ISO 18000-6C Compliant
UHF RFID 4-Port | 8-Port Reader AZF-M1
Cables to Connect 15m for 9 & 12 dBi
15-Meter Cable for UHF RFID Fixed Reader AZF-M1
