AD Miniweb U9 FCC label is a compact (45×18 mm) ARC-certified RFID solution for retail, industrial, and supply-chain use. It delivers strong read performance on low-detuning materials such as cardboard and plastic, and in close-coupled environments. Powered by NXP® UCODE® 9, it offers 96-bit EPC memory and a self-adjusting feature that optimizes performance in challenging conditions. Widely applied in retail chains like Dillard’s, it ensures accurate inventory tracking, reliable performance, and smooth in-store operations.
Material: Coated Paper Label Size: 45×18 mm Antenna Size: 42×16 mm
Technical Parameters
Operating Frequency:860~960 MHz Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen 2v2.1 ARC Specs: F,O,Q,W5,W6 Certificate: ARC Read Range: Up to 16.5 m ESD Voltage Immunity: Max.2000V Operating Mode: Passive
Additional Information
Operating Environment: -40°C ~ 85°C Storage Environment: 18°C ~ 28°C , 40%~60% RH Handling Precautions: 1. Do not bend. 2. Keep away from water and collision. 3. Labels with black-dot marks are bad ones, do not use.
Chip Characteristics
Chip Manufacturer:NXP® Chip Type:UCODE® 9 Data Retention: 20 years EPC Memory: 96 bits TID Memory: 96 bits Write Endurance: 100,000 times User Memory: 0 bits Security Features: 32 bits Kill Password Read Sensitivity: -24 dBm Write Sensitivity: -22 dBm
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag Roll OD: Max.230mm Core ID: 3 inch(76.2±0.50 mm) Packing Quantity: 5000 pcs/roll, per roll 3 kg.
Reading Range under different frequency
Above graph shows multiple testing results with the same tag.
Orientation Sensitivity
Above graph shows multiple testing results with the same tag.
Loooking for More Products? search or use the categories
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
Avery Dennison® ARC Certified NXP® UCODE® 9 RFID Label | 45×18mm
$308.00
AD Miniweb U9 FCC label is a compact (45×18 mm) ARC-certified RFID solution for retail, industrial, and supply-chain use. It delivers strong read performance on low-detuning materials such as cardboard and plastic, and in close-coupled environments. Powered by NXP® UCODE® 9, it offers 96-bit EPC memory and a self-adjusting feature that optimizes performance in challenging conditions. Widely applied in retail chains like Dillard’s, it ensures accurate inventory tracking, reliable performance, and smooth in-store operations.
Description
Features
Frequency Band
UHF 860~960 MHz
Chip Type
NXP UCODE® 9
International Standard
ISO/IEC 18000-6C, EPC Global Gen2v2.1
EPC Memory
96 bits
TID Memory
96 bits
Read Range
Up to 16.5 m
Specifications
Physical Specifications
Material: Coated Paper
Label Size : 45×18 mm
Antenna Size : 42×16 mm
Technical Parameters
Operating Frequency: 860~960 MHz
Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen 2v2.1
ARC Specs: F,O,Q,W5,W6
Certificate: ARC
Read Range: Up to 16.5 m
ESD Voltage Immunity: Max.2000V
Operating Mode: Passive
Additional Information
Operating Environment: -40°C ~ 85°C
Storage Environment: 18°C ~ 28°C , 40%~60% RH
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Labels with black-dot marks are bad ones, do not use.
Chip Characteristics
Chip Manufacturer: NXP®
Chip Type: UCODE® 9
Data Retention: 20 years
EPC Memory: 96 bits
TID Memory: 96 bits
Write Endurance: 100,000 times
User Memory: 0 bits
Security Features: 32 bits Kill Password
Read Sensitivity: -24 dBm
Write Sensitivity: -22 dBm
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Roll OD: Max.230mm
Core ID: 3 inch(76.2±0.50 mm)
Packing Quantity: 5000 pcs/roll, per roll 3 kg.
Reading Range under different frequency
Orientation Sensitivity
