Dogbone® Impinj® Monza® R6-P PET UHF RFID Wet Inlay | 97×27mm
$667.00
The Impinj® Monza® R6-P UHF Dogbone® RFID wet inlay is designed for high-performance UHF RFID applications across global supply chains. It features the Impinj® Monza® R6-P chip and supports EPC Global Gen2v2 and ISO/IEC 18000-6C protocols for fast, accurate reads. Operating in the 860–960 MHz UHF band, the label uses a clear PET facestock and measures 97 × 27 mm, optimized for long read range and reliable performance.
Operating Environment: -40°C~85°C Storage Environment: 18°C~28°C,40%~60% RH Handling Precautions: 1. Do not bend. 2. Keep away from collision. 3. Inlays with black-dot marks are bad ones, do not use.
Chip Characteristics
Chip Manufacturer:Impinj® Chip Type:Impinj® Monza® R6-P Data Retention: 50 years EPC Memory:96/128 bits User Memory: 32/64 bits TID Memory: 96 bits Write Endurance:100,000 times Read Sensitivity:-22 dBm Write Sensitivity: -17 dBm Serial Number:48 bits AutoTune™Automatic RF Tuning:Standard Integra™Memory Diagnostics:Standard Enduro™Robust Bonding Construction: Copper Plating FastID™ High-speed Reading:Support Security Features:32 bits Kill & Access Password
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag Roll OD: 4 inch/100 mm Core ID:3 inch(76±0.50 mm) Packing Quantity:1000 Pcs/roll.per roll 1 kg
Reading Range
Orientation Sensitivity
Loooking for More Products? search or use the categories
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
Dogbone® Impinj® Monza® R6-P PET UHF RFID Wet Inlay | 97×27mm
$667.00
The Impinj® Monza® R6-P UHF Dogbone® RFID wet inlay is designed for high-performance UHF RFID applications across global supply chains. It features the Impinj® Monza® R6-P chip and supports EPC Global Gen2v2 and ISO/IEC 18000-6C protocols for fast, accurate reads. Operating in the 860–960 MHz UHF band, the label uses a clear PET facestock and measures 97 × 27 mm, optimized for long read range and reliable performance.
Description
Features
Frequency Band
UHF 860-960 MHz
Chip Type
Impinj® Monza® R6-P
International Standard
ISO/IEC 18000-6C, EPC Global Gen2v2
EPC Memory
96/128 bits
User Memory
32/64 bits
Read Range
Up to 16 m
Specifications
Physical Specifications
Material: PET
Label Size: 97×27 mm
Antenna Size: 94×24 mm
Technical Parameters
Operating Frequency: 860-960 MHz
Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen 2v2
Read Range: Up to 16 m
Operating Mode: Passive
Additional Information
Operating Environment: -40°C~85°C
Storage Environment: 18°C~28°C,40%~60% RH
Handling Precautions:
1. Do not bend.
2. Keep away from collision.
3. Inlays with black-dot marks are bad ones, do not use.
Chip Characteristics
Chip Manufacturer: Impinj®
Chip Type: Impinj® Monza® R6-P
Data Retention: 50 years
EPC Memory: 96/128 bits
User Memory: 32/64 bits
TID Memory: 96 bits
Write Endurance: 100,000 times
Read Sensitivity:-22 dBm
Write Sensitivity: -17 dBm
Serial Number: 48 bits
AutoTune™Automatic RF Tuning: Standard
Integra™Memory Diagnostics: Standard
Enduro™Robust Bonding Construction: Copper Plating
FastID™ High-speed Reading: Support
Security Features: 32 bits Kill & Access Password
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Roll OD: 4 inch/100 mm
Core ID: 3 inch(76±0.50 mm)
Packing Quantity: 1000 Pcs/roll.per roll 1 kg
Reading Range
Orientation Sensitivity
