Flexible & Printable Long Range On-Metal NXP® UCODE® 8 RFID Label | 60×25 mm
$200.00–$571.00Price range: $200.00 through $571.00
The NXP® UCODE® 8On-Metal Printable UHFRFID Label is designed for secure and reliable identification of metallic assets in demanding industrial and supply chain environments. Compliant with ISO/IEC 18000-6C and EPC Global Gen2v2, this label can be easily integrated into existing UHF RFID systems for accurate asset tracking, inventory management, and supply chain visibility. With its folded side-flap structure, the label helps reduce interference from surrounding materials, enabling a longer and more stable UHF RFID read range. It is a practical solution for metal asset identification, equipment tracking, warehouse management, and industrial applications.
Material: PET & Aluminum Foil & Foam Label Size: 60×25×1 mm(L×W×T) IP Rating: IP68, test for 5 hours at 1m deep water Supported Printers: Sato CL4NNX, Zebra ZT411 Silverline, Postek TX3r, etc Customization Options: Print logo, barcode/QR code, serial number, encoding, design, etc.
Technical Parameters
Operating Frequency: 902-928 MHz Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen 2v2 Read Sensitivity: -23 dBm Write Sensitivity: -18 dBm Operating mode: Passive Read Range(FCC): Up to 9.5m (On-metal, Fixed Reader) Up to 6m (On-metal, Handheld Reader)
Chip Characteristics
Chip Manufacturer:NXP® Chip Type:UCODE® 8 Data Retention: 10 years EPC Memory: 128 bits User Memory: 0 bits TID Memory: 96 bits Write Endurance: 100,000 times Kill&Access Password: 32 bits Self-Adjust Function: Support Untraceable Function: Support Integrated Product Status Flag(PSF): Support Pre-serialization for 96-bit EPC: Support Compatible with Single-slit Antenna: Support
Additional Information
Operating Environment: -40°C ~ 85°C, 35% ~ 65% RH Storage Environment: 18°C ~ 28°C, 40% ~ 60% RH Handling Precautions: 1. Do not bend. 2. Keep away from water and collision. 3. Labels with black-dot marks are bad ones, do not use.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag Roll OD: Max.8.7 inch/220 mm Core ID: 3 inch(76.20 ± 0.50) mm Packing Quantity: 500 Pcs/roll, per roll 0.85 kg Carton Dimension: 47×47×12 cm
Reading Range Under Different Frequency
Tag Power Under Different Frequency
Loooking for Brand Protection System? BrandGuard™ Might Help
A luxury-focused identity infrastructure that protects premium products through secure NFC authentication, copy-resistant digital identity, and real-time brand governance.
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
Flexible & Printable Long Range On-Metal NXP® UCODE® 8 RFID Label | 60×25 mm
$200.00 – $571.00Price range: $200.00 through $571.00
The NXP® UCODE® 8 On-Metal Printable UHF RFID Label is designed for secure and reliable identification of metallic assets in demanding industrial and supply chain environments. Compliant with ISO/IEC 18000-6C and EPC Global Gen2v2, this label can be easily integrated into existing UHF RFID systems for accurate asset tracking, inventory management, and supply chain visibility. With its folded side-flap structure, the label helps reduce interference from surrounding materials, enabling a longer and more stable UHF RFID read range. It is a practical solution for metal asset identification, equipment tracking, warehouse management, and industrial applications.
Description
Features
Frequency Band
UHF 902-928 MHz
Chip Type
NXP® UCODE® 8
International Standard
ISO/IEC 18000-6C, EPC Global Gen 2v2
EPC Memory
128 bits
TID Memory
96 bits
User Memory
0 bits
Specifications
Physical Specifications
Material: PET & Aluminum Foil & Foam
Label Size: 60×25×1 mm(L×W×T)
IP Rating: IP68, test for 5 hours at 1m deep water
Supported Printers: Sato CL4NNX, Zebra ZT411 Silverline, Postek TX3r, etc
Customization Options: Print logo, barcode/QR code, serial number, encoding, design, etc.
Technical Parameters
Operating Frequency: 902-928 MHz
Communication Protocol:
ISO/IEC 18000-6C, EPC Global Gen 2v2
Read Sensitivity: -23 dBm
Write Sensitivity: -18 dBm
Operating mode: Passive
Read Range(FCC):
Up to 9.5m (On-metal, Fixed Reader)
Up to 6m (On-metal, Handheld Reader)
Chip Characteristics
Chip Manufacturer: NXP®
Chip Type: UCODE® 8
Data Retention: 10 years
EPC Memory: 128 bits
User Memory: 0 bits
TID Memory: 96 bits
Write Endurance: 100,000 times
Kill&Access Password: 32 bits
Self-Adjust Function: Support
Untraceable Function: Support
Integrated Product Status Flag(PSF): Support
Pre-serialization for 96-bit EPC: Support
Compatible with Single-slit Antenna: Support
Additional Information
Operating Environment: -40°C ~ 85°C, 35% ~ 65% RH
Storage Environment: 18°C ~ 28°C, 40% ~ 60% RH
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Labels with black-dot marks are bad ones, do not use.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Roll OD: Max.8.7 inch/220 mm
Core ID: 3 inch(76.20 ± 0.50) mm
Packing Quantity: 500 Pcs/roll, per roll 0.85 kg
Carton Dimension: 47×47×12 cm
Reading Range Under Different Frequency
Tag Power Under Different Frequency
