$200.00–$571.00Price range: $200.00 through $571.00
The 70×30mm NXP® UCODE® 8 Flexible & Printable UHF On-Metal RFID Label is specifically engineered to deliver high-performance tagging in challenging environments where traditional RFID labels fail. Equipped with the advanced UCODE® 8 IC, it offers fast inventory counting, exceptional read sensitivity, and long read ranges even when applied directly to metal surfaces. The flexible structure ensures reliable performance on curved or irregular assets, making it ideal for IT equipment, machinery, tools, and metallic containers.
Designed for seamless integration into asset management and industrial workflows, this label supports EPC Global Gen 2v2 and ISO/IEC 18000-6C standards and features a printable surface, allowing users to customize graphics, barcodes, or variable data via standard RFID printers. Its durable construction ensures strong adhesion and resistance to harsh conditions, including abrasion, temperature fluctuations, and moisture. With a balance of flexibility, robustness, and high RF efficiency, this on-metal UHF label provides a dependable solution for accurate tracking across demanding applications.
Material: PET + Aluminum Foil + Foam Label Size: 70×30×1 mm (L×W×T) IP Rating: IP68, test for 5 hours at 1m deep water Support Printer: SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc. Personalized Printing: Printing Logo, Barcodes, Serial Number, Encoding, Designing, etc
Operating Environment: -20°C ~ 50°C, 20% ~ 80% RH Storage Environment: 18°C ~ 28°C , 40%~60% RH Handling Precautions: 1. Do not bend. 2. Keep away from water. 3. Labels with black-dot marks are bad ones, do not use.
Chip Characteristics
Chip Manufacturer:NXP® Chip Type:UCODE® 8 Data Retention: 20 years EPC Memory: 128 bits TID Memory: 96 bits Write Endurance: 100,000 times Unique Serial Number: 48 bits Read Range(Fixed Reader): 10m on metal (ETSI), 12m on metal (FCC) Read range(Handheld Reader): 8m on metal(ETSI), 6m on metal(FCC) Kill Password: 32 bits Access Password: 32 bits
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag Roll OD: Max.220mm Core ID: 3 inch(76.2±0.50 mm) Packing Quantity: 500 pcs/roll, per roll 1 kg.
Reading Range @ETSI Standard
Reading Range @FCC Standard
Loooking for More Products? search or use the categories
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
Flexible & Printable On-Metal UHF RFID Label NXP® UCODE® 8 | 70×30mm
$200.00 – $571.00Price range: $200.00 through $571.00
The 70×30mm NXP® UCODE® 8 Flexible & Printable UHF On-Metal RFID Label is specifically engineered to deliver high-performance tagging in challenging environments where traditional RFID labels fail. Equipped with the advanced UCODE® 8 IC, it offers fast inventory counting, exceptional read sensitivity, and long read ranges even when applied directly to metal surfaces. The flexible structure ensures reliable performance on curved or irregular assets, making it ideal for IT equipment, machinery, tools, and metallic containers.
Designed for seamless integration into asset management and industrial workflows, this label supports EPC Global Gen 2v2 and ISO/IEC 18000-6C standards and features a printable surface, allowing users to customize graphics, barcodes, or variable data via standard RFID printers. Its durable construction ensures strong adhesion and resistance to harsh conditions, including abrasion, temperature fluctuations, and moisture. With a balance of flexibility, robustness, and high RF efficiency, this on-metal UHF label provides a dependable solution for accurate tracking across demanding applications.
Description
Features
Frequency Band
UHF 865~868 MHz(EU)
Chip Type
NXP UCODE® 8
International Standard
ISO/IEC 18000-6C, EPC Global Gen2v2
EPC Memory
128 bits
TID Memory
96 bits
Read Range (Fixed Reader)
10m, on metal(ETSI), 12m on metal (FCC)
Specifications
Physical Specifications
Material: PET + Aluminum Foil + Foam
Label Size : 70×30×1 mm (L×W×T)
IP Rating : IP68, test for 5 hours at 1m deep water
Support Printer : SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc.
Personalized Printing : Printing Logo, Barcodes, Serial Number, Encoding, Designing, etc
Technical Parameters
Operating Frequency: 865~868 MHz (EU)
Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen 2v2
Read Sensitivity: -23 dBm
Write Sensitivity: -18 dBm
Operating Mode: Passive
Additional Information
Operating Environment: -20°C ~ 50°C, 20% ~ 80% RH
Storage Environment: 18°C ~ 28°C , 40%~60% RH
Handling Precautions:
1. Do not bend.
2. Keep away from water.
3. Labels with black-dot marks are bad ones, do not use.
Chip Characteristics
Chip Manufacturer: NXP®
Chip Type: UCODE® 8
Data Retention: 20 years
EPC Memory: 128 bits
TID Memory: 96 bits
Write Endurance: 100,000 times
Unique Serial Number: 48 bits
Read Range(Fixed Reader): 10m on metal (ETSI), 12m on metal (FCC)
Read range(Handheld Reader): 8m on metal(ETSI), 6m on metal(FCC)
Kill Password: 32 bits
Access Password: 32 bits
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Roll OD: Max.220mm
Core ID: 3 inch(76.2±0.50 mm)
Packing Quantity: 500 pcs/roll, per roll 1 kg.
Reading Range @ETSI Standard
Reading Range @FCC Standard
