Operating Environment:
-5°C ~ 60°C, 20% ~ 80% RH
Storage Environment:
20°C ~ 30°C, 20% ~ 60% RH
Passed Test:
REACH Regulation(EC) No.1907/2006
RoHS EU Directive 2011/65/EC and Directive(EU) 2015/863
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Labels with black-dot marks are bad ones, do not use.
Application:
Inventory and Logistics, Sports Timing, Supply Chain Management.
Avery Dennison®Impinj® M730 AD Dogbone® RFID Label
$77.00
The AD Dogbone® M730 label, designed by Avery Dennison, is tailored for global supply chain, logistics, and sports timing applications. It excels in harsh environments and features the Impinj® M730 IC chip with 128-bit EPC memory and auto-tuning capabilities, providing high read/write sensitivity and rapid data retrieval. Compatible with the GS1 UHF Gen2v2 standard, it includes a loss prevention mode to effectively protect consumer privacy.
Description
Features
Frequency Band
UHF 860~960 MHz
Chip Type
Impinj® M730
International Standard
ISO/IEC 18000-6C
EPC Memory
128 bits
TID Memory
48 bits
Certificate
WEEE compliant
Specifications
Physical Specifications
Material: Clear PET
Label Size: 96×26 mm
Antenna Size: 94×24 mm
Technical Parameters
Operating Frequency: 860~960 MHz
Communication Protocol:
ISO/IEC 18000-6C
Operating mode: Passive
ESD Voltage Immunity: Max. 2000V (HBM)
Chip Characteristics
Chip Manufacturer: Impinj®
Chip Type: M730
EPC memory: 128 bits (read & write)
Password: 32-bit Access, 32-bit Kill
TID memory: 48 Bits(Read only)
Read sensitivity: -24 dBm
Write sensitivity: -21 dBm
AutoTune™ Automatic RF Tuning: V2
Enduro™ Bonding Method: V1
Integra™ Data Diagnostics: Yes
Fast Encoding Speeds: Yes
FastID™ High-speed Read Capability: Yes
TagFocus™ Read Redundancy Prevention: Yes
Write Endurance: 10,000 times
Data Retention Time: 50 years
Additional Information
Operating Environment:
-5°C ~ 60°C, 20% ~ 80% RH
Storage Environment:
20°C ~ 30°C, 20% ~ 60% RH
Passed Test:
REACH Regulation(EC) No.1907/2006
RoHS EU Directive 2011/65/EC and Directive(EU) 2015/863
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Labels with black-dot marks are bad ones, do not use.
Application:
Inventory and Logistics, Sports Timing, Supply Chain Management.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Core ID: 3 inch (76.20 ± 0.50 mm)
Packing Quantity: 7500 Pcs/roll, 4 rolls/carton
Reading Range in Class 1 Materials
Reading Range in Class 2 Materials
Orientation-Sensitivity
