The Flexible & Printable UHF On-metal Label equipped with NXP UCODE® 8 is a durable, customizable, high-performance RFID label that can be easily printed and encoded. The label is ideal for metallic container tracking, equipment & device tracking, warehouse shelf, automotive components tracking, IT asset tracking, etc. It can be stuck on metallic asset easily, specially for irregular and uneven surface.
Material: PET & Aluminum Foil & Foam Label Size: 50×15×1 mm(L×W×T) IP Rating: IP68 test for 5 hours at 1m deep water Personalized Printing: Logo, barcode/QR code, number printing, encoding, etc.
Technical Parameters
Operating Frequency: 902~928 MHz (US) Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen2v2 Read sensitivity: -23 dBm Write sensitivity: -18 dBm Read Range(Fixed Reader): 7.6 m on metal (US); 6.5m, on metal (EU)
Chip Characteristics
Chip Manufacturer:NXP® Chip Type:UCODE® 8 Data Retention: > 10 years EPC Memory: 128 bits TID Memory: 96 bits Write Endurance: 100,000 times Access/Kill password: 32 bits
Packaging
Packing quantity:500pcs/roll Roll method: Packed in roll Reel coreinner dimension: 3inch (76.20±0.50 mm) Installation: Directly stick on objects
Additional Information
Operating Environment: -40°C ~ 85°C Storage Environment: -40°C ~ 120°C Support Printer: SATO CL4NX,Zebra ZT411 Silverline, Postek TX3r, etc. Application: – Metallic container tracking – Equipment & device – Tracking Warehouse shelf – Automotive components tracking – IT asset tracking, etc. Handling Precautions: 1. Do not bend. 2. Keep away from water and collision. 3. Labels with black-dot marks are bad ones, do not use.
Reading Range under different frequency
Tag Power under different frequency
UHF On-Metal RFID Labels On Different Metal Surfaces: Test Results Comparison
Surface Type
Max Reading Distance (m)
Read Success Rate
Non-Metal
1.0
100%
Steel
4.2
100%
Aluminum
1.6
100%
Iron
6.2
100%
All test data were obtained using a UHF RFID handheld reader (SKU: AZH-P1) for reference only. Actual performance may vary depending on the customer’s on-site testing results.
Performance Testing Of UHF On-Metal RFID Lables On Different Metal Surfaces
Effective Asset Tracking For Metal Surfaces And Multiple Environments
Loooking for More Products? search or use the categories
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
On-metal RFID Label NXP UCODE® 8 | 50×15mm
$92.00 – $659.00Price range: $92.00 through $659.00
The Flexible & Printable UHF On-metal Label equipped with NXP UCODE® 8 is a durable, customizable, high-performance RFID label that can be easily printed and encoded. The label is ideal for metallic container tracking, equipment & device tracking, warehouse shelf, automotive components tracking, IT asset tracking, etc. It can be stuck on metallic asset easily, specially for irregular and uneven surface.
Description
Features
Frequency Band
UHF 902~928 MHz (US)
Chip Type
NXP UCODE® 8
International Standard
ISO/IEC 18000-6C,EPC Global Gen2v2
EPC Memory
128 bits
TID Memory
96 bits
IP Rating
IP68
Specifications
Physical Specifications
Material: PET & Aluminum Foil & Foam
Label Size: 50×15×1 mm(L×W×T)
IP Rating: IP68 test for 5 hours at 1m deep water
Personalized Printing: Logo, barcode/QR code, number printing, encoding, etc.
Technical Parameters
Operating Frequency: 902~928 MHz (US)
Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen2v2
Read sensitivity: -23 dBm
Write sensitivity: -18 dBm
Read Range(Fixed Reader): 7.6 m on metal (US); 6.5m, on metal (EU)
Chip Characteristics
Chip Manufacturer: NXP®
Chip Type: UCODE® 8
Data Retention: > 10 years
EPC Memory: 128 bits
TID Memory: 96 bits
Write Endurance: 100,000 times
Access/Kill password: 32 bits
Packaging
Packing quantity:500pcs/roll
Roll method: Packed in roll
Reel coreinner dimension: 3inch (76.20±0.50 mm)
Installation: Directly stick on objects
Additional Information
Operating Environment: -40°C ~ 85°C
Storage Environment: -40°C ~ 120°C
Support Printer: SATO CL4NX,Zebra ZT411 Silverline, Postek TX3r, etc.
Application:
– Metallic container tracking
– Equipment & device
– Tracking Warehouse shelf
– Automotive components tracking
– IT asset tracking, etc.
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Labels with black-dot marks are bad ones, do not use.
Reading Range under different frequency
Tag Power under different frequency
UHF On-Metal RFID Labels On Different Metal Surfaces: Test Results Comparison
All test data were obtained using a UHF RFID handheld reader (SKU: AZH-P1) for reference only. Actual performance may vary depending on the customer’s on-site testing results.
Performance Testing Of UHF On-Metal RFID Lables On Different Metal Surfaces
Effective Asset Tracking For Metal Surfaces And Multiple Environments
