Avery Dennison®Impinj® M730 RFID Label 80x55mm
$19.00 – $474.00Price range: $19.00 through $474.00
The label can be used as a unique identifier for items in footwear and apparel retail, logistics, and supply chains. Even in close-proximity item stacking situations, it provides high read reliability, excellent orientation sensitivity, and outstanding performance. It fully complies with ISO/IEC 18000-6C and EPCglobal Gen2v2 standards.
Description
Features
Frequency Band
UHF 860~960 MHz
Chip Type
Impinj® M730
International Standard
ISO/IEC 18000-6C, EPCglobal Gen2v2
EPC Memory
128 bits
Max. Read Range (ETSI)
16 m
Max Read Range (2W ERP FCC)
17.5 m
Specifications
Physical Specifications
Material: PP Synthetic Paper
Size: 80×55 mm
Antenna Size: 50×30 mm
Technical Parameters
Operating Frequency: 860~960 MHz
Communication Protocol:
ISO/IEC 18000-6C, EPCglobal Gen2v2
Read Range:
865~868 MHZ (EU): Up to 17.5 m
902~928 MHz (US): Up to 16 m
ESD Voltage Immunity: Max. 2000V
Operating mode: Passive
Chip Characteristics
Chip Manufacturer: Impinj®
Chip Type: M730
EPC memory: 128 bits
User memory: 0 bits
TID memory: 48 bits
Access&Kill Password: Shared 32 bits
Write Endurance: 100,000 cycles
Read/Write sensitivity:
-11 dBm (ETSI standard)
-16 dBm (FCC standard)
Additional Information
Operating Environment:
Label attach: 10°C ~ 40°C, 20% ~ 80% RH
After label attached: -20°C ~ 50°C, 20% ~ 80% RH
Storage Environment:
18°C ~ 28°C, 40% ~ 60% RH
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Labels with black-dot marks are bad ones, do not use.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Roll OD Size: Max. 140 mm
Core Size: 3 inch (76.20 ± 0.50 mm)
Packing Quantity: 1000 Pcs/roll, per roll 0.855 kg
Reading Range under different frequency
Orientation Sensitivity
