Tamper-Evident On-Metal UHF RFID Label Alien® Higgs® 9 | 75×25mm
$285.00–$813.00Price range: $285.00 through $813.00
The 75×25mm Alien® Higgs® 9 Flexible & Printable UHF On-Metal RFID Label is specifically engineered to deliver high-performance tagging in challenging environments where traditional RFID labels fail.Equipped with the advanced Higgs® 9 IC, it offers fast inventory counting, exceptional read sensitivity, and long read ranges even when applied directly to metal surfaces. The flexible structure ensures reliable performance on curved or irregular assets, making it ideal for IT equipment, machinery, tools, and metallic containers.
Designed for seamless integration into asset management and industrial workflows, this label supports EPC Class 1 Gen 2 and ISO/IEC 18000-6C standards and features a printable surface, allowing users to customize graphics, barcodes, or variable data via standard RFID printers. Additionally, its tamper-proof design, made from fragile material, ensures security—once installed, it will be damaged if removed, providing a clear indication of tampering.
Material: PET + Aluminum Foil + Foam Label Size: 75×25×1.25 mm (L×W×T) IP Rating: IP68, test for 5 hours at 1m deep water Support Printer: SATO CL4NX, Zebra ZT411 Silverline, Postek TX3r, etc. Personalized Printing: Printing LOGO, Barcode, Serial number, Encoding, Designing, etc.
Chip Manufacturer:Alien® Chip Type:Higgs® 9 Data Retention: 50 years User Memory: 688 bits Unique TID Memory: 48 bits EPC Memory: 96-496 bits Write Endurance: 200,000 times Read Range(Fixed Reader): 7.5m on metal Read Range(Handheld Reader): 4.5m on metal Kill Password: 32 bits Access Password: 32 bits
Additional Information
Hermal Endurance: -40°C ~ 120°C Operating Environment: -20°C ~ 50°C, 20% ~ 80% RH Storage Environment: 18°C ~ 28°C, 40% ~ 60% RH Handling Precautions: 1. Do not bend. 2. Keep away from water and collision. 3. Labels with black-dot marks are bad ones, do not use.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag Core ID: 3 inch(76.2±0.50 mm) Packing Quantity: 500 pcs/roll, 1 kg. Packing Weight: 4 rolls/carton, G.W.: 4 kg. Carton Dimension: 47×47×12cm
Testing Graphs Reading Range Under Different Frequency
Testing Graphs Tag Power Under Different Frequency
Loooking for More Products? search or use the categories
As a leading RFID hardware manufacturer for over a decade, we are committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and stringent quality control ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Our expert team drives innovation in RFID technology. Whether you need custom solutions or cutting-edge products, we provide advanced and effective RFID solutions tailored to your needs.
EFFICIENT & RELIABILITY
We offer reliable global shipping with in-stock items delivered within 1-3 business days in North America, Europe, and the Asia Pacific. Our proven track record ensures your satisfaction every time.
Tamper-Evident On-Metal UHF RFID Label Alien® Higgs® 9 | 75×25mm
$285.00 – $813.00Price range: $285.00 through $813.00
The 75×25mm Alien® Higgs® 9 Flexible & Printable UHF On-Metal RFID Label is specifically engineered to deliver high-performance tagging in challenging environments where traditional RFID labels fail.Equipped with the advanced Higgs® 9 IC, it offers fast inventory counting, exceptional read sensitivity, and long read ranges even when applied directly to metal surfaces. The flexible structure ensures reliable performance on curved or irregular assets, making it ideal for IT equipment, machinery, tools, and metallic containers.
Designed for seamless integration into asset management and industrial workflows, this label supports EPC Class 1 Gen 2 and ISO/IEC 18000-6C standards and features a printable surface, allowing users to customize graphics, barcodes, or variable data via standard RFID printers. Additionally, its tamper-proof design, made from fragile material, ensures security—once installed, it will be damaged if removed, providing a clear indication of tampering.
Description
Features
Frequency Band
UHF 865-868 MHz (EU)
Chip Type
Alien® Higgs® 9
International Standard
ISO/IEC 18000-6C, EPC Class 1 Gen 2
EPC Memory
96-496 bits
User Memory
688 bits
Unique TID Memory
48 bits
Specifications
Physical Specifications
Material: PET + Aluminum Foil + Foam
Label Size: 75×25×1.25 mm (L×W×T)
IP Rating: IP68, test for 5 hours at 1m deep water
Support Printer: SATO CL4NX, Zebra ZT411 Silverline, Postek TX3r, etc.
Personalized Printing: Printing LOGO, Barcode, Serial number, Encoding, Designing, etc.
Technical Parameters
Operating Frequency: UHF 865-868 MHz
Communication Protocol:
ISO/IEC 18000-6C, EPC Class 1 Gen 2
Operating mode: Passive
Read Sensitivity: -20 dBm
Write Sensitivity: -18 dBm
Chip Characteristics
Chip Manufacturer: Alien®
Chip Type: Higgs® 9
Data Retention: 50 years
User Memory: 688 bits
Unique TID Memory: 48 bits
EPC Memory: 96-496 bits
Write Endurance: 200,000 times
Read Range(Fixed Reader): 7.5m on metal
Read Range(Handheld Reader): 4.5m on metal
Kill Password: 32 bits
Access Password: 32 bits
Additional Information
Hermal Endurance: -40°C ~ 120°C
Operating Environment:
-20°C ~ 50°C, 20% ~ 80% RH
Storage Environment:
18°C ~ 28°C, 40% ~ 60% RH
Handling Precautions:
1. Do not bend.
2. Keep away from water and collision.
3. Labels with black-dot marks are bad ones, do not use.
Packaging
Packing Format: Packed in roll, vacuumed packing in ESD bag
Core ID: 3 inch(76.2±0.50 mm)
Packing Quantity: 500 pcs/roll, 1 kg.
Packing Weight: 4 rolls/carton, G.W.: 4 kg.
Carton Dimension: 47×47×12cm
Testing Graphs Reading Range Under Different Frequency
Testing Graphs Tag Power Under Different Frequency
